Tamper Evident Labeling Machine
The primary purpose of tamper-evident labeling machine is to affix safety seal labels onto cartons, these labels serve as crucial safeguard against tampering and counterfeiting. By using pressure-sensitive labels, which resistant to water and hot air, the tamper-evident feature is reinforced. Attempting to remove the label from the packaging would result in visible damage to the applied surface, effectively indicating any manipulation or unauthorized access.
Key Features
- Robust construction in stainless steel.
- Mitsubishi PLC controlled with touch screen panel.
- Easy adjusting hand wheels for quick changeover.
- 50 job memory for easy set-up and recall.
- Stepper drive label applicator.
- Wipe down device.
- Throughput speeds up to 30 pcs per minute.
Options
- Coding system: hot stamp or thermal-transfer printer
- Verification system: bar code, imprinting presence and correctness, label presence
- Transparent label sensor
Specifications
| Label Type | Adhesive label |
|---|---|
| Carton Length Range | 105-170mm |
| Carton Height Range | 40-80mm |
| Label Height Range | 20-80mm |
| Label Length Range | 20-80mm |
| Conveyor Width | 50mm |
| Conveyor Length | 2750mm |
